Aluminum Grating
Aluminum grating in 6061 / 6063 alloy, swage-locked or press-locked construction, custom bearing bar height, thickness and pitch. Factory-direct supply for walkways, platforms, stair treads and trench covers.
Aluminum Grating Quick Specs
| Parameter | Range |
|---|---|
| Material Alloy | 6061-T6 / 6063-T5 / 5052 |
| Bearing Bar Height | 20 – 100 mm |
| Bearing Bar Thickness | 2 – 10 mm |
| Bearing Bar Pitch | 20 / 30 / 40 / 60 mm |
| Cross Bar Pitch | 50 / 100 mm |
| Panel Size | Up to 1200 × 3600 mm |
| Surface Finish | Mill / Anodized / Powder Coated |
Aluminum Grating Specifications
| Bearing Bar Height (mm) | Bearing Bar Thickness (mm) | Bearing Bar Pitch (mm) | Cross Bar Pitch (mm) | Weight (kg/m²) | Panel Size (mm) | Available Alloy |
|---|---|---|---|---|---|---|
| 20 | 2 | 20 | 50 | 6.2 | 1000 × 2000 | 6063-T5 |
| 25 | 3 | 30 | 50 | 9.4 | 1000 × 2000 / 1000 × 3000 | 6063-T5 / 6061-T6 |
| 30 | 3 | 30 | 100 | 8.1 | 1000 × 3000 | 6063-T5 / 6061-T6 |
| 32 | 3 | 40 | 100 | 6.8 | 1000 × 3000 / 1200 × 3600 | 6061-T6 |
| 40 | 4 | 40 | 100 | 10.5 | 1000 × 3000 / 1200 × 3600 | 6061-T6 |
| 50 | 5 | 50 | 100 | 12.8 | 1000 × 3000 / 1200 × 3600 | 6061-T6 / 5052 |
| 60 | 5 | 50 | 100 | 15.1 | 1200 × 3600 | 6061-T6 / 5052 |
| 75 | 6 | 60 | 100 | 18.4 | 1200 × 3600 | 6061-T6 / 5052 |
| 100 | 8 | 60 | 100 | 26.7 | 1200 × 3600 | 6061-T6 / 5052 |
Custom bearing bar height, thickness, pitch and panel sizes available. Send your load and span requirements for a tailored quotation.
Aluminum Grating Types & Construction
Swage-Locked Aluminum Grating
Bearing bars and cross bars are assembled and locked by a swaging press. No welding, no rivets. Suitable for walkways, platforms and general industrial flooring.
Press-Locked Aluminum Grating
Bearing bars and cross bars are locked by high pressure without swaging. Provides a smooth, tight surface with high rigidity, suitable for architectural and visible applications.
Riveted Aluminum Grating
Cross bars are riveted to bearing bars. Suitable for heavy-duty platforms and where additional connection strength is required.
Aluminum Grating Ceiling
Linear aluminum grating used as open-cell suspended ceiling, sunshade and decorative screen for architectural projects.
Applications
Walkway & Platform
Walkways, operating platforms, catwalk flooring, inspection platforms.
Stair Treads & Ladders
Stair treads, ladder rungs, safety steps.
Trench & Drainage Cover
Trench covers, drainage grates, sump covers.
Architectural & Decorative
Suspended ceilings, sunshades, facades, decorative screens.
Quality & Supply
Material Traceability — Every aluminum billet and finished panel is batch-recorded from incoming inspection to packing.
In-House Quality Control — Bearing bar height, thickness, pitch and panel squareness are measured on every production batch.
Load & Span Support — Bearing bar selection is confirmed against your load and span requirements before production.
Packing & Loading — Steel-strapped bundles or wooden pallets, seaworthy packing for container loading.
Related Products
FAQ
Aluminum Grating — FAQ
Q: What is aluminum grating?
Aluminum grating is a load-bearing panel made from aluminum bearing bars and cross bars, locked together by swaging, pressing or riveting. It is used for walkways, platforms, stair treads and trench covers.
Q: What is the difference between aluminum grating and steel grating?
Aluminum grating is lighter and naturally corrosion-resistant, making it suitable for coastal, marine and lightweight platform applications. Steel grating has higher strength and lower material cost, but requires galvanizing or painting for corrosion protection.
Q: What bearing bar height and pitch can you manufacture?
We produce bearing bar heights from 20 mm to 100 mm, thickness from 2 mm to 10 mm, and bearing bar pitch of 20 / 30 / 40 / 60 mm.
Q: Can you produce custom panel sizes?
Yes. Panels up to 1200 × 3600 mm are available. Custom cutting, notching and edge banding can be produced against your drawing.
Q: What surface finishes are available?
Mill finish, anodizing and powder coating. Anodizing is recommended for exterior and coastal applications.
Q: What is the typical lead time?
Standard panels ship in 7–15 days. Custom sizes and surface finishes typically require 15–25 days depending on quantity.
Need a Custom Aluminum Grating Specification?
Send your bearing bar height, thickness, pitch, panel size, load and span requirements. We will reply with a factory quotation and lead time within 24 hours.
